Solar Inverters With Transformer

Sunny Mini Central 7000 HV

The champion for thin-film projects

More modules can be connected in series with the Sunny Mini Central 7000HV than with common inverters. This reduces cabling costs on the DC side and simplifies the installation. Due to its galvanic separation, the device can be used both with crystalline cells and thin film modules. Its performance range allows the installation of large PV arrays using smaller string inverters, resulting in more detailed PV plant monitoring. Its new reactive power and grid management functions mean it is also suitable for demanding applications.



Sunny Mini Central 7000 HV

The champion for thin-film projects

•    Topology: LF transformer
•    Max. DC-voltage: 800 V
•    Max. AC-power: 7000 W

Efficient

•    OptiCool active temperature management
•    OptiTrac MPP tracking for best tracking efficiency

Reliable

•    Galvanic isolation
•    Integrated ESS DC switch-disconnector
•SMA Power Balancer for three-phase grid connection

Flexible

•    Integrated reactive power capability and grid management functions
•    Input voltage range of up to 800 V
•    Suitable for PV array grounding

Simple

•    SUNCLIX DC plug system

Accessories:

RS485 interface Piggy-Back

Whether for planning a new PV plant or for the expansion of an existing plant communication: plant yields can be continuously monitored with the SMA communications interfaces. From the Piggy Back to the Data Module - cable connected or with wireless Bluetoothฎ technology - SMA offers a self-developed communication system with a multitude of robust interfaces from the industrial area of application. Subsequent expansions are possible without problem thanks to the modular design principle.



Bluetooth interface Piggy-Back




SMA Power Balancer plug-in system PBL-SMC10-NR




Grounding Set "positive" ESHV-P-NR

When using thin-film or rear-side contact PV modules, it may be necessary to ground the positive or negative connection of the PV array. Our grounding set offers you the perfect solution for this.

The grounding set provides you with the following advantages:

•    The set is available for both the positive and also negative grounding.
•    Internal grounding saves time by making it unnecessary to change external generator cabling.
•    The grounding is fused by an internal thermal fuse and therefore provides additional safety (fire protection).
•    The grounding sets can be seamlessly integrated into the inverter. This completely preserves the insulation monitoring. This important safety feature of SMA devices can identify possible insulation faults within the generator.




Grounding Set "negative" ESVH-P-NR

When using thin-film or rear-side contact PV modules, it may be necessary to ground the positive or negative connection of the PV array. Our grounding set offers you the perfect solution for this.

The grounding set provides you with the following advantages:

•    The set is available for both the positive and also negative grounding.
•    Internal grounding saves time by making it unnecessary to change external generator cabling.
•    The grounding is fused by an internal thermal fuse and therefore provides additional safety (fire protection).
•    The grounding sets can be seamlessly integrated into the inverter. This completely preserves the insulation monitoring. This important safety feature of SMA devices can identify possible insulation faults within the generator.
